Radial Dry Cooler
A sturdy, compact and stackable dry cooler
Designed and made to be modular. The Dry Cooler Radial is built with double-wall panels in galvanised steel and mineral wool in the hollow space for soundproofing and heat insulation. Powder coated (standard colour: RAL 7035).
Capacity
40-245 kW
*Standard conditions EN1048
Number
of fans
of fans
1 - 4
Fan
diameter
diameter
500mm (AC)-630mm (EC)
Finned pack heat exchangers
With OVAL SECTION tubes:
12 mm nominal diameter; staggered pitch pattern and high-efficiency fins.
12 mm nominal diameter; staggered pitch pattern and high-efficiency fins.
With ROUND SECTION tubes:
12 mm or with 5/8” nominal diameter, staggered pitch pattern and high-efficiency fins. Standard fin pitch: 2.1 mm.
12 mm or with 5/8” nominal diameter, staggered pitch pattern and high-efficiency fins. Standard fin pitch: 2.1 mm.
Fans
- Radial fans
Dimension
Applications
Air
conditioning
conditioning
